Home > PRODUCT > ALUX









   CPU

   CANTUS 32bit 96MHz

   Frequency

   ISO14443 Type A Mifare Card Interface

   Program Memory

   512KByte Flash

   Data Memory

   80KByte SRAM

   Read Range

   40~80mm À̳»

   Card Read Time    0.1sec (Typical)

   Indicator

   Matrix LED

   Buzzer

   Melody °æº¸À½

   Output interface

   Wiegand  34Bits, RS485

   Baud rate

   4,800~115,200bps

   Host Communication    USB

   Color

   Silver

   Operating temperature

   -10¡É ~ 55¡É

   Storage temperature

   -10¡É ~ 60¡É

   Power supply input

   +12V DC

   Dimensions

   64W x 105H x 20D(mm)
