CPU

   VIA C7 1.2GHz  nanoBGA2

   Memory

   2G Flash Disk

   Display

   7” TFT- LCD TOUCH SCREEN

   CAMERA

   410,000 Pixel CCD Camera

   INTERPHONE

   Interphone & Call Switch

   FRR(False Rejection Rate)

   0.01%

   FRR(False Acceptance Rate)

   0.00008%

   The Number Of Palm Vein ID

   More Than 100,000

   Sensor Input

   4Port

   Relay Output

   4Port

   Event Log Save

   More than 500,000

   RFID

   HF ISO-1443 A/ B, ISO-18000-3
   ISO-18000-2, UHF ISO-18000-6

   NETWORK INTERFACE

   TCP/IP, RS485, Wire-less Network(Option)

   PC INTERFACE

   USB, RS232C

   SUB INTERFACE

   Wiegand, TTL, RS232C

   USER FUNCTION 1

   USB Memory Stick

   USER FUNCTION 2

   Camera,Mike,Speaker

   USER FUNCTION 3

   Company Bulletin Board, Media Player,Life Information

   Dimensions

   199 X 431 X 143(77.8) mm
