| Door Open control |
PIN / Master number / RF Card / Remote control(447Mhz |
| Card Type |
Mifare, ISO14443A/B(13.56MHz) |
| Keypad |
Touch key(12Key) |
| Data storage capacity |
Max. 200 cards |
| Communication method |
Wireless(Z-Wave), Wire(RS-485 |
| Power supply |
DC 12V(by power supply) or DC 6V (AA type 1.5V alkaline battery x 4),
DC 9V (Emergency power) |
| Operating temperature |
-15~55℃ |
Operating temperature of
high
temperature Sensor |
65℃ |
| Electic shock |
30KV |
| Weight |
In body : 375.5g, Out body : 623.5g |
| Color |
Black / Silver |
| Dimensions(㎜) |
In body : 77W x 212H x 72D, Out body : 81W x 215H x 72D |
|
|
|
|
