Frequency

   13.56MHz

   Card (Transponder)

   ISO14443 Type A Mifare Card Interface

   Memory

   1~8 Kbyte

   Read range

   40~80mm 이내

   Card read time

   0.1sec (typical)

   Indicator

   2 LED, Dual color

   Buzzer

   500msec  경보음

   Output interface

   Wiegand  34Bits, RS485

   Baud rate

   4,800~115,200bps

   Color

   Silver/Gold

   Operating temperature

   -10℃ ~ 55℃

   Storage temperature

   -10℃ ~ 60℃

   Power supply input

   +12V DC

   Dimensions

   85W x 137H x 20D(mm)
