| CPU |
32bit Micro processor(400MHz) |
| Memory |
NAND Flash 128Mbyte, 64Mbyte RAM |
| Sensor |
Optic, 500DPI |
| Wiegand port |
2 Wiegand Input ports |
| User Registration |
6,000 Fingerprints, 100,000 cards, 200,000 log data |
| Communication |
TCP/IP, RS-485, RS-232 |
| Sound/Alarm |
Buzzer, Voice guidance |
| Built-in RF Option |
Mifare(13.56MHz, ISO14443A) : Basic, EM(125KHz), UHF(915Mhz) |
| Camera(Pro version only) |
Built-in Camera(NTSC), Proximity Sensor, DVR connection |
| Dimension(㎜) |
149(W)x132(L)x52(D) |
|
