 Home > PRODUCT > ATR-310 |
|
|
| |
|
|
 Frequency |
13.56MHz |
|
Card
(Transponder) |
ISO14443
Type A Mifare
Card Interface |
|
Memory |
1~8 Kbyte |
| High Security |
Sector or Serial Reader |
|
Read
range |
40~80mm |
|
Card
read time |
0.1sec
(typical) |
|
Indicator |
2 LED,
Dual color |
|
Buzzer |
500msec
Buzzer
|
|
Output
interface |
Wiegand
34Bits, RS485 |
|
Baud
rate |
4,800~115,200bps |
|
Color |
Silver/Gold |
|
Operating
temperature |
-10℃
~ 55℃ |
|
Storage
temperature |
-10℃
~ 60℃ |
|
Power
supply input |
+12V DC |
|
Dimensions |
85W
x 137H x 20D(mm) |
|
|
|
|
